Pallet Racking Solutions in Rancho Cucamonga, California
Rancho Cucamonga is a key Inland Empire logistics location with a growing number of distribution centers. ATB Material Handling provides pallet racking systems that support high-volume storage and smooth operations.
Pallet Racking Products and Services
Warehouses in Rancho Cucamonga require pallet racking solutions that balance capacity and accessibility. ATB Material Handling offers systems designed for a wide range of applications.
Available options include selective pallet racking, push-back racking, drive-in systems, and pallet flow solutions. These systems help warehouses store more product while maintaining efficient access.
As experienced pallet racking suppliers in Rancho Cucamonga, California, ATB Material Handling supports customers with design, installation, and ongoing service. Layouts are customized to fit building dimensions and workflow.
Pallet racking services also include system upgrades and expansions as operations evolve.
Warehouse Pallet Rack Systems Built Around Your Facility
ATB Material Handling provides complete pallet rack planning, supply, and installation services for businesses that need to maximize storage capacity without compromising accessibility or safety. Whether you are outfitting a new warehouse, redesigning an existing space, or replacing damaged rack components, ATB can coordinate the project from initial site review through final installation.
Our capabilities include warehouse space planning, rack layout development, material procurement, seismic calculations, permit coordination, and installation by experienced professionals.
Essential Rack System Components
Pallet racking is a coordinated assembly of structural members, storage surfaces, connectors, and protective equipment. ATB can provide the components needed to create a complete and properly configured system:
- Vertical frames: Upright assemblies transfer pallet weight to the floor and establish each rack bay’s depth and overall height.
- Load beams: Horizontal beam pairs span between upright frames to create pallet storage levels.
- Wire-mesh decking: Steel deck panels provide an added support surface for cases, irregular loads, and pallets that do not rest evenly on the beams.
- Row connectors: Back-to-back spacers join adjacent rack rows, add lateral stability, and preserve the flue space between stored products.
- Forklift-impact protection: Guards for uprights, columns, and aisle ends help protect critical rack areas from accidental contact with lift trucks.
- Anchors and base plates: Engineered anchorage secures uprights to the slab and can be designed for applicable seismic and building-code conditions.
Storage Rack Options
Different inventory types and operating demands call for different rack designs. ATB offers several common systems for palletized, oversized, and heavy-duty storage applications.
- Roll-formed rack: A practical option for standard warehouse operations, roll-formed racking uses adjustable beam levels and teardrop-style connections. It is well suited to facilities that expect to change their layout or add capacity over time.
- Structural rack: Structural systems use hot-rolled steel members for added strength in demanding environments. They are often selected for heavy products, busy lift-truck traffic, and operations where durability is a priority.
- Cantilever storage: Rather than using front beams, cantilever racks use arms that extend from vertical columns. This open design makes them a strong fit for long materials such as lumber, pipe, bar stock, steel tubing, and furniture.
Matching Existing Rack Systems
Expanding an existing rack installation does not always require a complete replacement. ATB can help identify and source compatible components for established rack systems, including Interlake (Mecalux), Nucor, and Spacerack.
Additional manufacturers may be supported based on the profile, connection type, dimensions, and loading requirements of the installed system. This can make repairs, phased expansions, and replacement-part sourcing more efficient.
Common Dimensions and Custom Layouts
ATB offers frequently requested rack sizes for standard applications, as well as engineered configurations for facilities with specialized requirements.
Component | Available or Common Sizes |
Upright frame depth | 36 in., 42 in., 44 in., or 48 in. |
Upright frame height | 8 ft., 12 ft., 16 ft., 20 ft., or 24 ft.; taller engineered systems available |
Beam length | 48 in., 96 in., 108 in., 120 in., or 144 in. |
Wire decking | 42 in. × 46 in. and 42 in. × 52 in. |
A 42-inch-deep frame is a widely used choice, while 96-inch beams are commonly configured for two pallet positions. For unique pallet dimensions, high clear heights, unusual building footprints, or application-specific capacity needs, ATB can develop a custom rack design that aligns with the facility’s storage goals.
Supporting Rancho Cucamonga Warehouses
Rancho Cucamonga supports retail, manufacturing, and third-party logistics operations. Many warehouses handle high throughput and require dependable storage systems.
Pallet racking solutions in Rancho Cucamonga focus on maximizing vertical space and maintaining safe forklift movement. ATB Material Handling works closely with facilities to ensure systems meet operational needs.
The area continues to grow, making scalable pallet racking an important investment.
Frequently Asked Questions
Selective pallet racking offers flexibility, while push-back systems increase density.
Yes. ATB Material Handling offers full pallet racking services from start to finish.
Yes. Many pallet rack solutions can be reconfigured.
Yes. Inspections and repairs help keep systems safe.
Plan Smarter Pallet Racking for Rancho Cucamonga Facilities
Rancho Cucamonga warehouses continue to expand in size and complexity, increasing the need for efficient storage systems. Pallet racking solutions must support high inventory volumes while remaining flexible as operations evolve. ATB Material Handling provides pallet racking systems designed to meet these demands.
If your facility is planning upgrades, expansions, or safety improvements, experienced pallet racking services can help streamline the process. Speak with the team by calling 323-726-9424 or contact us to plan pallet racking solutions for your Rancho Cucamonga warehouse.
